Recommended selling points: Extremely fast charging, especially suitable for the European and American large-capacity energy storage market, lithium phosphate battery, ultra-long service life, high conversion rate, OEM labeling.
Parameters: Waveform: Sine wave LiFePO4 battery
Battery pack: 1120Wh (LiFePO4 7S1P, 22.4V/50Ah)
Rated power: 1000W peak 2000W (2 milliseconds)
Input:
AC socket charging: Charging power 800W
It takes 9-10 minutes to charge the first 90%; it takes about 80 minutes to charge 80%; it takes about 90 minutes to charge 90%; it takes about 112 minutes to charge 100%;
Anderson: 120W (11-26V/5AMAX, supports MPPT)
Output:
AC output: 100-240V 50Hz /60Hz
(Voltage and socket specifications of different countries can be customized)
2 DC outputs: 12V/5A 60W max
Car charger output port: 12V/10A 120W max
2 USB-QC3.0 outputs: 5V/3A, 9V/2A, 12V/1.5A 18W MAX
1 TYPE-C 100W: 5V/9V/12V/15V-3A, 20V/5A 100W max
1 TYPE-C 30W: 5V/9V/3A, 12V/2.5A, 15V/2A, 30W max
Wireless charging: 15W
LED light: 4W (red and white)
Working temperature: -10~40℃
Life cycle: >2000 times
Safety protection: Multiple protections (a. short circuit b. overpower c. overvoltage d. low voltage e. overload f. overtemperature)
Product size: 326*236*285mm
Outer box size: 415*325*375mm
Fe-Li single unit net weight: 12kg gross weight: 14.9kg
Customization: can be customized in different colors and different national specifications
Input conversion: 90% Output conversion: inverter has a conversion rate of 92%
