Electric Vehicles

8

Human-machine interface

7-inch LCD touch color screen + LED

9

Networking mode

Ethernet, 4G (optional)

10

Charging mode

Automatic full charge, by time, by power, by amount

11

Starting mode

Card swipe, code scan (APP, WeChat applet, public account, etc.)

12

Protection function

Gun temperature detection, short circuit, over temperature, over current, leakage, over voltage, lightning protection

13

Charging mode

Full power charging, AB equalization charging

14

Cloud platform

Support cloud fast charging, Weijingyun, Xingxing charging, Xiaoju, Dakyun, State Grid e charging

15

Input voltage

AC380V±20%

16

Input frequency

50Hz±10%

17

Output voltage range

DC200-1000V

18

Constant power output voltage range

DC300-1000V

19

Single-gun maximum output current

200A                              250A

20

Output voltage error

≤±0.5%

21

Output current error

≤±1%

22

Voltage regulation accuracy

≤±0.5%

23

Current regulation accuracy

≤±1%

24

Nobo content

≤5%

25

Power factor

≥0.99 (50% load or more)

26

Maximum efficiency

≥95%

27

Electric energy measurement

1.0 level, in line with GB standard

28

Insulation resistance

≥20MΩ

29

Noise

II level

30

Protection level

IP54

31

Usage environment

Indoor or outdoor

32

Cooling method

Air cooling

33

Operating temperature

-20℃-+50℃

34

Storage temperature

-40℃-+70℃

35

Relative humidity

5%-95% non-condensing

36

Altitude

≤2000m

37

Auxiliary power supply

12V/DC

38

Installation method

Floor-standing

39

Advertising screen

32 inches (optional)
